ASTM A105 Gate Valve
Company Info |
|
| Company Name | China Bosseal Valves Factory Co., Ltd. |
| Country/Territory: | China |
| Business Type: | | Distributor/Wholesaler, Manufacturer |
| Number of Employees: | 51 - 100 People |
| Main Products: ball valves | |
>> Details:
1500 LB BW End Forged Gate Valve Made from Valve Manufacturers, A105 Body, Trim 5, API 602, 0.5 INCH, 1500 LB, Handwheel
Valve Description:
1851008 API 602 Forged Gate Valve 0.5G15BA10505
Design Standard: API 602, ASME B16.34
Structure: Bolted Bonnet, OS & Y
Nominal size: 1/2 Inch
Nominal class: 1500 LB
Bore: Regular Bore
End Connection: BW, Butt Weld End
Operation: Handwheel
Body Material: ASTM A105
Trim Material: 1CR13+STL.6, Trim 5
Face-to-face: Manufacturer Standard
Test and inspection: API 598
Key Features: Independent backseat, Fully guided solid wedge, Adjustable Packing Gland
Product Range:
Body material: Carbon Steel, Stainless Steel, Duplex steel, Alloy
Normal diameter: 1/2-2 Inch (DN15 - DN50)
Pressure range: Class 900-2500 LB
End connection: BW, Butt Weld
Working temperature: -29ˇć - +500ˇć
Operation: Handwheel
