Rising Stem Cast Steel Gate Valve Class600/900/15
Company Info |
|
| Company Name | Shanghai Ciphy Industry Co.,Ltd. |
| Country/Territory: | Shanghai China |
| Business Type: | | 1;2;5;8;9 |
| Number of Employees: | |
| Main Products: gate valve ball valve globe valve check valve | |
>> Details:
SAAXRF-RS
OUTSIDE SCREW AND YOKE;
BOLTED BONNET;
FLEXIBLE WEDGE, FULLY GUIDER;
INTEGRAL SEATS;
RISING STEM HANDWHEEL;
AVAILABLE WITH GEAR OPERATOR;
FLANGED ENDS OR BUTT-WELDING ENDS;
RISING FLANGE OR RING TYPE JOINT.
SIZE:DN20-DN600
WORKING TEMPERATURE:
CARBON STEEL :CELSIUS SCALE -29 C~425 C
FAHRENEIT (6 F~822 F)
STAINLESS STEEL :CELSIUS SCALE -40 C~550
FAHRENEIT 15 F~1047 F
GENERAL DESIGN SPECIFICATIONS:
MANUFACTURE :API 6D OR API600 BS1414
PRESSURE-TEMPERATURE RATINGS: ANSI B16.34 BS1560
FACE TO FACE :ANSI B16.10 BS2080
END TO END :ANSI B16.10 BS 2080
END FLANGE :ANSI B16.5 BS1560
END BUTT-WELDING :ANSI B16.25 BS 1414
GASKET CONTACT:ANSI B16.5 BS 1560
INSPECTION AND TEST :API598 BS 6755 PART 1
