T&P Valve

1, Commodity name: Temperature and Pressure Relief Valve TP VALVE,P&T relief vlave

2, Use:T&P Valve for solar water heater, electric heater and so on

3, T&P relief Valve Function:

The T&P valve is designed to relieve the increase in pressure which develops during the normal heating cycle.

This is caused by the water expanding during the heating cycle.The T/P valve then will relieve the increase in pressure by releasing drips of hot water to the drain line. It is recommended that an expansion control valve be fitted to the cold water supply line as it will relieve cold water(not hot water),during the heating cycle expansion,thereby saving energy and increasing the life of the T&P relief valve.Local regulations may make it mandatory to install an expansion control valve in the cold water supply line.

Should the electrical temperature cut-out devices cease to operate correctly,the water will overheat and the temperature probe will then be activated to open the P/T valve,discharging hot water.

4, T/P relief valve for solar water heater

Inlet pressure control:

High pressure may cause excessive discharge and possible premature failure of the operating relief valve.The maximum water pressure usually occurs during the night, at the time of lowest water usage. In any mains pressure water heater installation,if the inlet water pressure exceeds 80% of the nominal set pressure of the operation relief valve,a pressure limiting valve must be fitted to the cold inlet.(If a cold water expansion control valve is fitted it will have a lower set pressure than the T/P relief valve and thus be classed as the "operating"relief valve.)

5,T&P Valve Installation:

T/P Valves should be installed by a licensed plumber.

If the temperature probe protruding from inside the inlet thread is damaged or bent,do not install,and obtain a replacement valve.

Clean out all deposits from the threaded boss on the heater before fitting a replacement valve,otherwise the new valve risks contamination and premature failure.Apply PTFE thread tape to the male taper thr
